SAHM Winder S100E

SAHM Winder S100E Specification

Product Type
Precision Yarn Winder

Material
High-grade Steel, Aluminum & Engineering Plastics

Capacity
Up to 12 Spindles per Machine

Computerized
Yes

Automatic Grade
Fully Automatic

Control System
Touch Panel PLC Based

Cooling System
Integrated Air Cooling

Spinning Method
Precision Winding

Voltage
230V / 380V, 50/60Hz

Power
0.15 kW per Spindle

Weight
Approx. 90 kg per Position

Dimension (L*W*H)
1520 x 570 x 1440 mm (per machine section)

Color
White/Blue/Grey

Noise Level
< 72 dB (A)

Yarn Types
Suitable for filament and technical yarns

Safety Features
Emergency Stop and Overload Protection

Yarn Count Range
10-5000 Denier

Tension Device
Electronic Yarn Tension Control

Maximum Package Diameter
320 mm

Drive System
Individual Spindle Drive with Frequency Inverter

Splice Option
Automatic Yarn Splicing Device Available

Display
Large LCD Multi-language Interface

Winding Speed
Up to 1200 m/min

Maximum Traverse Stroke
250 mm

SAHM Winder S100E Trade Information

Supply Ability
100 Per Month

Delivery Time
7 Days

SAHM Winder S100E About

For Sale: SAHM Winder S100E Brand: SAHM Model: S100E Year: 1995 Quantity: 1 Heads: 50 Frequency: 60Hz Reliable SAHM S100E Winder, designed for efficient and precise winding of yarns. With 50 winding heads and robust construction, this machine is ideal for industrial yarn processing, ensuring uniform package formation and consistent yarn tension. 50 winding heads for high-capacity production Industrial-grade design for durability and long service life Efficient winding for consistent yarn packages Frequency: 60Hz for smooth operation Suitable for a variety of yarn types and production settings

Advanced Precision Winding Technology

The S100E Winder is engineered for precision, offering a maximum package diameter of 320 mm and traverse stroke of 250 mm. Its electronic tension control and individual spindle drives provide uniform yarn winding, preventing material waste and ensuring high-quality output for both filament and technical yarns. The machine is fully computerized, delivering exceptional operational ease and minimizing manual intervention.

Intelligent Automation and Control

A user-friendly touch panel PLC controls the S100E, complemented by a large LCD display with multi-language support. Features such as automatic yarn splicing and real-time electronic tension regulation reduce downtime and improve operator efficiency. The S100E also incorporates emergency stop and overload protection, prioritizing safety during high-speed operations.

Built for Versatility and Durability

Constructed with high-grade steel, aluminum, and engineering plastics, the S100E ensures lasting performance. The integrated air cooling system maintains optimal operating temperatures, even at winding speeds up to 1200 m/min. Its modular design supports expansion up to 12 spindles per machine, offering adaptability for various production scales.

FAQ's of SAHM Winder a S100E:

Q: How does the electronic yarn tension control work on the SAHM Winder - S100E?

A: The S100E utilizes advanced electronic yarn tension control to precisely monitor and adjust yarn tension throughout the winding process. This technology, paired with individual spindle drives, ensures uniform package formation and consistent product quality for diverse yarn types.

Q: What yarn types and counts can be processed on this machine?

A: The SAHM Winder - S100E is designed to handle a wide range of yarn types, including filament and technical yarns, with a yarn count range from 10 up to 5000 denier. This versatility allows it to meet requirements for various industrial applications.

Q: When is the automatic yarn splicing device used in the winding process?

A: The automatic yarn splicing device engages whenever a yarn break is detected or during package changeovers. This feature quickly and securely reconnects yarn ends, minimizing machine downtime and ensuring a seamless production workflow.

Q: Where can the SAHM Winder - S100E be installed and operated?

A: The S100E can be installed in a variety of industrial environments across India, including textile manufacturing, technical yarn processing, and filament production facilities. Its compact section dimensions and modular design facilitate flexible plant layouts.

Q: What is the process for operating the SAHM Winder - S100E?

A: Operators use the touch panel PLC and multi-language LCD to set winding parameters, such as speed, package diameter, and tension. The machine automates much of the process, including spindle control and yarn splicing, while built-in safety and cooling systems maintain optimal working conditions.

Q: How does the S100E benefit production operations?

A: By offering high winding speeds up to 1200 m/min, electronic tension control, and full automation, the S100E increases productivity, reduces labor involvement, and delivers consistent quality. Its safety features and robust construction minimize maintenance and operational risks.
