Open end machine

Open end machine Specification

Product Type
Open End Spinning Machine

Material
Mild Steel / Stainless Steel

Capacity
Depends on configuration (typically 120-360 rotors)

Computerized
Yes

Automatic Grade
Automatic

Control System
PLC Controlled

Cooling System
Air cooled

Spinning Method
Open End

Voltage
380V/415V, 50/60 Hz

Power
15-50 kW (depending on model)

Weight
Approx. 5-10 tons (varies by configuration)

Dimension (L*W*H)
Customized (e.g., 12000 mm x 2500 mm x 2500 mm)

Color
Blue/White (customized options available)

Yarn Count Range
Ne 6s - Ne 40s

Yarn Quality Sensor
Integrated online monitoring

Production Rate
Up to 180 kg/h

Doffing System
Automatic doffing

Installation Service
Available

Drafting System
Precision 3-roller drafting

Display Interface
Touch screen panel

Noise Level
Below 80 dB

Lubrication System
Centralized automatic lubrication

Feed Material
Cotton, synthetic fibers, blends

Rotor Speed
Up to 120,000 rpm

Sliver Can Size
Standard 18"/24"/36"

Power Supply
Three Phase

About Open end machine

For Sale: ICBT Twisters a DT 350 EH Brand: ICBT Model: DT 350 EH Year: 1999 Number of Machines: 4 Positions: 96 each Serial Numbers: VA 98363/2-2 Voltage: 3 A 575a V (600a V) Frequency: 60a Hz Current: 70a A Compressed Air: 5a bar, 1a mA /h Technical Specifications Supply Package Max Diameter: 8.5a Compatible Packages: 11a cardboard tubes, package dye tubes, 7a cones Twist Range: 150a 500a d Twist per Inch: 1a 4 (historic) Drive Type: Gear driven Description High-performance ICBT DT 350 EH Twisters, designed for efficient twisting of yarns with precision and consistency. Each machine features 96 twisting positions and supports a variety of package types, making them ideal for industrial yarn production across a range of deniers and twists. Gear-driven twisting ensures uniform yarn tension and quality, while the machinesa robust design provides long-term reliability. Suitable for twisting fine to medium denier yarns for textiles, industrial, or specialty applications. 4 machines with 96 positions each for high-volume twisting Supports multiple package types: cardboard tubes, dye tubes, 7a cones Twist range 150a 500a d, 1a 4 twists per inch Gear-driven system for consistent yarn quality Industrial-grade design for long-term reliability Compressed air operation at 5a bar, 1a mA /h

Advanced Spinning Performance

Harness state-of-the-art capabilities with rotor speeds reaching 120,000 rpm and an automated doffing system. The machine produces a wide range of yarn counts and excels with cotton, synthetic, or blended fibers, ensuring high output rates and consistent quality.

Precision and Versatility

Featuring a 3-roller drafting system and integrated online yarn sensors, this open end spinning machine guarantees optimal fiber alignment and defect detection. Choose from varied sliver can sizes and customizable configurations to meet specific production demands.

Operator-Centric and Efficient Design

With a user-friendly touchscreen interface and PLC controls, operators can easily monitor and adjust machine settings. Centralized automatic lubrication, air-cooled operation, and a noise level below 80 dB provide a comfortable and safe working environment.

FAQ's of Open end machine:

Q: How does the automatic doffing system work on this open end spinning machine?

A: The automatic doffing system enables the machine to efficiently replace filled bobbins with empty ones without halting production. This minimizes downtime, boosts productivity, and reduces manual intervention, streamlining your spinning operations.

Q: What materials can be processed on this machine, and is it suitable for blends?

A: This open end spinning machine can process cotton, synthetic fibers, and blended materials. Its advanced drafting and rotor system are designed to handle a variety of fiber types and combinations, providing versatility for diverse yarn production requirements.

Q: When should I schedule routine maintenance, and what systems aid in this process?

A: Routine maintenance intervals depend on usage intensity, but the centralized automatic lubrication system significantly extends service life and reduces maintenance frequency. Integrated sensors and online monitoring also alert operators to any anomalies, facilitating proactive maintenance.

Q: Where is installation service available, and who provides support?

A: Installation services for the open end spinning machine are available across India through authorized service providers, suppliers, and traders. Comprehensive support, including setup, training, and maintenance, ensures seamless integration into your facility.

Q: What are the key benefits of the integrated online yarn quality monitoring sensor?

A: The online yarn quality monitoring sensor continuously checks for irregularities during production, ensuring consistency and rapid identification of defects. This real-time quality assurance enhances overall product reliability and minimizes waste.

Q: How does the PLC control system enhance production?

A: The PLC (Programmable Logic Controller) system automates machine control, enables precise adjustments, and simplifies parameter changes. Combined with a touchscreen panel, it provides intuitive operation, better error handling, and streamlined production management.
